Advantage 5th Gen 9k BTU 115V Air Handler
Component — Not a Complete System
This is the indoor unit only. To run, you also need a matching outdoor condenser and a refrigerant line set. Looking for the complete system instead? Browse complete systems.
SKU A-09-HP-WMAH-115D-O
Customize it — compatible add-ons only
Copper pair in 1/4″ × 3/8″ — the diameter this unit's spec sheet calls for. Installed and charged by your HVAC tech.
Clean channel for the lines running down your exterior wall.
Universally compatible tools and care items — maintenance kit, coil cleaner, install tools.
Sizing Help
Not sure if this system is right for your space?
Proper sizing prevents short-cycling, high bills, and premature failure. Our sizing tool takes 60 seconds.
Resources
Brochures & Manuals
Description
Advantage 5th Gen 9k BTU 115V Air Handler
What's in the Box
Here's what you'll receive with your order
Wall-Mount Air Handler
Indoor ductless mini-split unit
Wireless Remote Control
Handheld remote with temperature control
Mounting Plate & Hardware
Wall mounting bracket and screws
Owner Manual
Installation and operation guide
Key Specifications
115V
Voltage
33.5dBA
Noise Level
Advantage 5th Gen 9k BTU 115V Air Handler — Model Details
What this specific model is sized for, how it installs, how it performs, and what it costs to run.
Power & Electrical Requirements
Power requirement: 115V 1-phase 60Hz (standard US 120V household outlet). Minimum circuit ampacity is 3A with a maximum overcurrent protection of 15A. Wire the outdoor unit with 14 AWG copper on a dedicated 15A double-pole breaker (or single-pole at 120V), with a disconnect within sight of the condenser per NEC 440.14.
Install Difficulty — Professional Install
This is a professionally-installed condenser that requires a licensed HVAC technician with EPA 608 certification. The tech will pull a vacuum on the line set to 500 microns, pressure-test with nitrogen, release the factory charge, and commission per MrCool's startup procedure. Budget 1 full day for install on a single-zone system. The system supports line set lengths up to 82ft; longer runs are available as accessory kits. Plan the shortest practical route — every 10ft of line set adds roughly 2% capacity loss.
Sound Level & Comfort Features
Operating sound level ranges from 18 dB(A) on low to 43 dB(A) on high — the low end is whisper-quiet, below a normal conversation (60 dB) and comparable to a library reading room. The indoor blower offers 5 fan speeds plus auto mode, letting you trade airflow for quiet operation in bedrooms while running louder in living areas.
Warranty & Certifications
Manufacturer warranty: 1 Year on parts, 2 Years on the compressor. AHRI certified and UL/ETL listed for North American electrical safety — required for most utility rebate and tax credit programs.
What's in the Box & Compatibility
Ships as a Mini-Split Air Handler with remote control included.
Product Details
The 5th Generation MRCOOL® 9k BTU 115V Advantage Air Handler now comes equipped with R454B refrigerant, the latest eco-friendly solution offering enhanced energy efficiency, reduced greenhouse gas emissions, and a lower Global Warming Potential (GWP). Designed for quiet operation, this Advantage mini-split unit delivers reliable heating and cooling for your home without the need for ductwork, ensuring an efficient and cost-effective solution for any space. Ideal for homeowners seeking an affordable yet powerful climate control system, the sleek Advantage air handler will give you the comfort you need all year long. With built-in Wi-Fi, you can conveniently control the unit via remote access, allowing it to automatically adjust the temperature overnight for optimal comfort and energy savings. Register your unit online and enjoy peace of mind with MRCOOL®’s robust warranty: 1 year on parts, 2 years on the compressor, and 1 year on the remote control. For further peace of mind, enroll in the MRCOOL® Care Program and enjoy our Limited Lifetime warranty. Say goodbye to comfort concerns with the MRCOOL® Advantage Air Handler!
Specifications
| Voltage | 115 V |
| Noise Level | 33.5 dBA |
| Max Line Set | 82 ft |
| Tonnage | 0.75 Ton |
| Airflow | 282.5 / 235.4 / 206.0 / 164.8 / 117.7 CFM |
| Phase | 1 |
| Liquid Line Size | 1/4 |
| Suction Line Size | 3/8 |
Features
- Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long term corrosion
- Includes features such as timer mode, refrigerant leakage detection, and more
- Keep the included remote close by, and MRCOOL DIY®'s Follow Me® function will track the air temperature around you to ensure maximum comfort.
- The MRCOOL® Smart HVAC Controller® Module and App fully support Google Assistant & Amazon Alexa out of the box.
- R-454B refrigerant
- AHRI certified
- NEEP ccASHP Listed
- CEE Tier1 - North
