GeoCool 48K BTU 4T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor
SKU GCSHPM048IN
Customize it — compatible add-ons only
Closed-loop (angled or straight manifold) or open-loop kit sized to this unit.
Factory-charged 3/8″ × 3/4″ quick-connect lines matched to this airflow configuration.
GeoCool air-return accessory for 48–60k multi-positional units.
For brazing the loop piping to the flare connections.
Universally compatible tools and care items — maintenance kit, coil cleaner, install tools.
Sizing Help
Not sure if this system is right for your space?
Proper sizing prevents short-cycling, high bills, and premature failure. Our sizing tool takes 60 seconds.
Resources
Brochures & Manuals
Description
GeoCool 48K BTU 4T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor
What's in the Box
Here's what you'll receive with your order
GeoCool 48K BTU 4T Multi Positional 230V 1-Phase 60Hz DC ...
As described
Key Specifications
Up to 50500BTU
Cooling Capacity
208 / 230V
Voltage
Up to 46500BTU
Heating Capacity
GeoCool 48K BTU 4T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor — Model Details
What this specific model is sized for, how it installs, how it performs, and what it costs to run.
Room & Space Coverage — 50,500 BTU
The GeoCool 48K BTU 4T Multi Positional 230V 1-Phase 60Hz DC Inverter Compressor delivers 50,500 BTU of cooling and heating capacity, sized for spaces 2,000+ sq ft in standard 8-ft ceiling rooms with average insulation. At this capacity the unit is typically used for open-plan main floors, large garages, pole barns, finished basements, and small commercial bays. For homes with vaulted ceilings, heavy sun exposure, or poor insulation, plan on ~20% more BTU per square foot than the nominal coverage.
Power & Electrical Requirements
Power requirement: 208 / 230V 1-phase 60Hz (standard US residential 240V service). Minimum circuit ampacity is 26A with a maximum overcurrent protection of 35A. Wire the outdoor unit with 8 AWG copper on a dedicated 35A double-pole breaker (or single-pole at 120V), with a disconnect within sight of the condenser per NEC 440.14.
Install Difficulty — Professional Install
This is a professionally-installed condenser that requires a licensed HVAC technician with EPA 608 certification. The tech will pull a vacuum on the line set to 500 microns, pressure-test with nitrogen, release the factory charge, and commission per MrCool's startup procedure. Budget 1 full day for install on a single-zone system. Ships with R-410A refrigerant. R-410A is a mature, widely-serviced refrigerant; service technicians and parts are available at any HVAC supply house.
Warranty & Certifications
Manufacturer warranty: 10 years on parts. AHRI certified — required for most utility rebate and tax credit programs.
What's in the Box & Compatibility
Ships as a Geothermal Heat Pump Compressor.
Product Details
Embrace comfort with the GeoCool® all DC Inverter Technology. Equipped with the highprecision Electronic Expansion Valve, allowing for more accurate temperature control while also keeping the utility bill down. The flexibility of four independent modules makes it easy to meet the installation requirements of different air outlet methods and applications. Space constraints are less of an issue when a custom built layout is an option! For a long term solution with lower maintenance costs, design your own GeoCool® Inverter Series Geothermal unit
Specifications
| Voltage | 208 / 230 V |
| Refrigerant | R-410A |
| Cooling Capacity | Up to 50500 BTU |
| Heating Capacity | Up to 46500 BTU |
| Phase | 1 |
| Refrigerant Type | R-410A |
Features
- Up to 70 EER
- DC Inverter technology
- Closed loop - Full load - Cooling Current Input: 13 Heating Current Input: 17 || Open Loop- Full Load - Cooling Current Input: 10 Heating Current Input: 17
- Open loop Operating Pressure Range: Min: 25 psi || Max: 50 psi
- Closed loop Operating Pressure Range: Min: 25 psi || Max: 50 psi
- Cooling Operating Range: Inlet: 44.6F - 107.6F || Ambient: 50F - 100.4F || Return Air: 60.8F - 89.6F
- Heating Operating Range: Inlet 21.2F - 89.6F || Ambient: 39.2F - 84.2F || Return Air: 50F - 80.6F
- Open loop - Full load - EER: 27.02 COP: 4.2 || Open Loop- Part Load - EER: 70.97 COP: 6.2
- Closed loop - Full load - EER: 18.29 COP: 3.4 || Closed Loop- Part Load - EER: 48.79 COP: 5.1
- Full Fluid Flow (GPM): 7.93 || Partial Fluid Flow (GPM): 7.93
