ProDirect·Pro InstallIndoor Unit Only

ProDirect 2 Ton 14 SEER Split System A/C Air Handler - Multiposition

Component — Not a Complete System

This is the indoor unit only. To run, you also need a matching outdoor condenser and a refrigerant line set. Looking for the complete system instead? Browse complete 24,000 BTU systems.

SKU HAH14024

24,000 BTUup to 1,200 sq ft14 SEER2208-230
$751.59
Pay over time withAffirmaffirmKlarnaKlarna— see your options at checkout.
Sold out at MrCool right now

Request a quote and we'll check when it's back, or match you to the closest in-stock unit.

We'll reply by email with availability or an in-stock alternative, and you can message us about it any time.

10 Year Limited Warranty warranty · Covers up to 1,200 sq ft
Ships nationwide · exact freight at checkout
30-day returns on unopened products · See policy
Secure checkout:Visa · Mastercard · Amex · Discover

Sizing Help

Not sure if 24K BTU is right for your space?

Proper sizing prevents short-cycling, high bills, and premature failure. Our sizing tool takes 60 seconds.

Match My SpaceOr call (657) 582-0899

Resources

Brochures & Manuals

BrochurePerformance SpecsInstall ManualWarranty

Description

ProDirect 2 Ton 14 SEER Split System A/C Air Handler - Multiposition

What's in the Box

Here's what you'll receive with your order

Wall-Mount Air Handler

Indoor ductless mini-split unit

Wireless Remote Control

Handheld remote with temperature control

Mounting Plate & Hardware

Wall mounting bracket and screws

Owner Manual

Installation and operation guide

2 Years compressor warranty
Compressor: 2 Years warrantyParts: 1 Year warranty

Key Specifications

24000BTU

Cooling Capacity

208-230V

Voltage

37-42dBA

Noise Level

ProDirect 2 Ton 14 SEER Split System A/C Air Handler - Multiposition — Model Details

What this specific model is sized for, how it installs, how it performs, and what it costs to run.

Room & Space Coverage — 24,000 BTU

The ProDirect 2 Ton 14 SEER Split System A/C Air Handler - Multiposition delivers 24,000 BTU of cooling and heating capacity, sized for spaces up to 1,200 sq ft in standard 8-ft ceiling rooms with average insulation. At this capacity the unit handles medium primary rooms, master suites with attached bath, converted garages, and workshops. If your space includes a sunny west-facing wall or a finished bonus room above it, lean toward the upper end of the coverage range.

Efficiency & Operating Cost

This unit is rated at 14 SEER2. SEER2 measures seasonal cooling efficiency — higher is better — and 14 meets current federal baseline. Running the unit 8 hours a day at full load draws roughly 411 kWh/month — about $66/month at the US average $0.16/kWh residential rate. Real-world draw is usually 30–50% lower because inverter compressors modulate down most of the time.

Power & Electrical Requirements

Power requirement: 208-230V 1-phase 60Hz (standard US residential 240V service).

Install Difficulty — Professional Install

This is a professionally-installed condenser that requires a licensed HVAC technician with EPA 608 certification. The tech will pull a vacuum on the line set to 500 microns, pressure-test with nitrogen, release the factory charge, and commission per MrCool's startup procedure. Budget 1 full day for install on a single-zone system.

Sound Level & Comfort Features

Operating sound level ranges from 37 dB(A) on low to 42 dB(A) on high — comparable to typical residential mini-split output. The indoor blower offers 3 fan speeds for basic airflow control.

What's in the Box & Compatibility

Ships as a Air Handler.

Product Details

Total comfort isn’t hard to attain when you have a unit like the multiposition MRCOOL ProDirect 2 Ton 14 SEER Split System Air Handler working in your home. This unit uses its “A” shaped evaporator coil to draw out all of the discomfort in your home, and once the air is ready to make you comfortable, it gets dispersed throughout your home by the three-speed direct drive blower motor. It goes through a removable filter to ensure the air is purified of contaminants so you’re only ever breathing crisp and clean air. It can also be installed in four airflow directions and with an electric heat kit, making it extremely accommodating. Your comfort will never be in danger thanks to the corrosion resistant galvanized steel cabinet that guards your unit from harm. There’s also a warranty that covers the air handler if you register online in case something goes wrong. To make your home feel better every day of the year without making your bills go higher and higher, have the ProDirect 2 ton split system air handler installed in your home.

Specifications

Cooling Capacity24,000 BTU
SEER2 Rating14
Voltage208-230 V
Noise Level37-42 dBA
SEER Rating14
Airflow938/804/738 CFM
Phase1
Country of OriginChina

Features

  • Equipment should be installed by a qualified professional
  • 10 Year Registered Warranty
  • AHRI Certified & ETL listed

Frequently Asked Questions

Everything you need to know about this product

What size room will the ProDirect 2 Ton 14 SEER Split System A/C Air Handler - Multiposition cool?

At 24,000 BTU this unit is sized for rooms up to 1,200 sq ft under standard 8-ft ceilings with average insulation. Add 10–20% for sun-exposed rooms, poorly insulated spaces, or ceilings above 9 ft.

Do I need a licensed HVAC installer?

Yes — this unit is professionally-installed. The installer needs EPA 608 certification to handle the refrigerant, plus standard HVAC tools (vacuum pump, manifold gauges, nitrogen kit). Expect a one-day install on a single-zone system, more on multi-zone.

Is this unit eligible for the federal 25C tax credit?

At 14 SEER2 this unit may not meet the 25C efficiency threshold — check the current ENERGY STAR CEE tier requirements. Confirm with your tax advisor and save the AHRI certificate from your order confirmation.

What electrical circuit do I need for installation?

208-230V dedicated circuit with the disconnect within sight of the outdoor unit per NEC 440.14. An electrician will size the breaker based on the minimum circuit ampacity shown on the nameplate. Budget $400–$900 for a new dedicated 240V circuit if one isn't already present.

How fast does HVACZAR ship this unit?

Shipping is calculated at checkout from the order weight, and you see the exact charge before paying. In-stock SKUs leave the warehouse within 1–3 business days. Transit time is 3–7 business days via truck freight (with liftgate delivery) for outdoor units and UPS Ground for accessories. Tracking is emailed at pickup.

What if it arrives damaged or I change my mind?

Inspect the unit before signing for freight delivery. If there is visible damage, note it on the delivery receipt and refuse the shipment — we ship a replacement at no cost. Unopened and unused units can be returned within 30 days for a refund less outbound shipping.

What is the warranty on the ProDirect 2 Ton 14 SEER Split System A/C Air Handler - Multiposition?

The ProDirect 2 Ton 14 SEER Split System A/C Air Handler - Multiposition comes with a 10 Year Limited Warranty manufacturer warranty when purchased from HVACZAR, an authorized MrCool dealer. Register your unit after purchase to activate full warranty coverage.

How long does shipping take?

Shipping is calculated at checkout from the order weight. Most MrCool systems ship within 1-3 business days and arrive in 3-7 business days via FedEx, UPS, or truck freight with liftgate delivery.

What size room does 24,000 BTU cover?

A 24,000 BTU unit is sized for rooms up to 1,200 sq ft. Proper sizing depends on ceiling height, insulation, climate zone, and window exposure. Use our system finder for a precise recommendation.

What is the efficiency rating?

This system is rated at 14 SEER2. Higher SEER2 ratings mean lower electric bills and better cooling efficiency.

Do you offer returns?

Yes. HVACZAR offers a 30-day return policy on unopened, unused products in original packaging. Contact us to initiate a return and receive a return authorization number.

How can I pay?

We accept all major credit cards (Visa, Mastercard, American Express, Discover) via Stripe secure checkout. All transactions are encrypted and protected.
