MRCOOL® VersaPro® 80k BTU 96% AFUE Gas Furnace
SKU MGM96EE080B3NB
Customize it — compatible add-ons only
Sits on the furnace to add AC/heat-pump cooling — width matches this furnace cabinet.
Seals the coil casing to the furnace for a clean transition.
MRCOOL 24V smart thermostat for ducted systems — Wi-Fi control and scheduling.
Maintenance kit and coil cleaner keep efficiency (and the warranty) healthy.
Universally compatible tools and care items — maintenance kit, coil cleaner, install tools.
Sizing Help
Not sure if this system is right for your space?
Proper sizing prevents short-cycling, high bills, and premature failure. Our sizing tool takes 60 seconds.
Resources
Brochures & Manuals
Description
MRCOOL® VersaPro® 80k BTU 96% AFUE Gas Furnace
What's in the Box
Here's what you'll receive with your order
MRCOOL® VersaPro® 80k BTU 96% AFUE Gas Furnace
As described
Key Specifications
115V
Voltage
MRCOOL® VersaPro® 80k BTU 96% AFUE Gas Furnace — Model Details
What this specific model is sized for, how it installs, how it performs, and what it costs to run.
Room & Space Coverage — 80,000 BTU
The MRCOOL® VersaPro® 80k BTU 96% AFUE Gas Furnace delivers 80,000 BTU of cooling and heating capacity, sized for spaces 2,000+ sq ft in standard 8-ft ceiling rooms with average insulation. At this capacity the unit is typically used for open-plan main floors, large garages, pole barns, finished basements, and small commercial bays. For homes with vaulted ceilings, heavy sun exposure, or poor insulation, plan on ~20% more BTU per square foot than the nominal coverage.
Efficiency & Operating Cost
On the gas side the unit achieves 96% AFUE, meaning 96¢ of every fuel dollar becomes usable heat — the rest exits through the flue.
Power & Electrical Requirements
Power requirement: 115V 1-phase 60Hz (standard US 120V household outlet). Minimum circuit ampacity is 8A with a maximum overcurrent protection of 15A. Wire the outdoor unit with 14 AWG copper on a dedicated 15A double-pole breaker (or single-pole at 120V), with a disconnect within sight of the condenser per NEC 440.14.
Install Difficulty — Professional Install
This is a professionally-installed condenser that requires a licensed HVAC technician with EPA 608 certification. The tech will pull a vacuum on the line set to 500 microns, pressure-test with nitrogen, release the factory charge, and commission per MrCool's startup procedure. Budget 1 full day for install on a single-zone system.
Warranty & Certifications
When you register your unit within 60 days of purchase you get 10 Years on parts through MrCool's registered warranty program. Unregistered coverage drops to 5 Years — registration takes 3 minutes at mrcool.com and is the highest-ROI post-purchase step you can take. AHRI certified and UL/ETL listed for North American electrical safety — required for most utility rebate and tax credit programs.
What's in the Box & Compatibility
Ships as a Gas Furnace.
Product Details
Even the harshest winters stand no chance against the efficient and quiet-running MRCOOL® VersaPro® 80k BTU 96% AFUE Gas Furnace. Thanks to its two-stage, consistent torque DC motor and 96% AFUE rating, you can relax knowing it's cutting down on your utility bills. Built with an aluminized steel tubular heat exchanger and stainless steel secondary heat exchanger, this furnace ensures both durability and reliability. Its compact design allows for easy installation, even in tight spaces. The furnace is designed for multi-position installation in upflow or horizontal configurations, with convenient left or right connections for gas or electric service. It also features a removable bottom panel for side or bottom return applications, simplifying both maintenance and installation processes. Additionally, it can be easily converted to propane with an optional LP kit. Being AHRI certified and ETL listed ensures the furnace meets rigorous quality and performance standards. Registering the furnace within 90 days activates a 10-year parts warranty and a lifetime warranty on the heat exchanger, providing added peace of mind. Even without registration, you're covered by a 5-year parts warranty and a 20-year heat exchanger warranty, ensuring long-term reliability and comfort.
Specifications
| Voltage | 115 V |
| Phase | 1 |
Features
- Intertek Cert: 3124627
- Filter Size:  Side Return: 16x25x1  Bottom Return: varies on furnace casing width 14x25 16x25 20x25 24x25
- Quiet Operation
- Superior Performance
- Durable Build & Finish
- Optional LP Kit
- Multi-Position Application
- 96% AFUE
- Two Stage
- Energy Efficient
- Compact Design
